The Complete Guide to Choosing the Right LED Wall Pack Lights

Kevin Hernandez

Outdoor safety, security, and curb appeal all depend on the right wall-mounted lighting. At NCLTG, we engineer commercial-grade LED wall pack lights that deliver uniform illumination, lower energy costs, and long-term reliability. Use this guide to compare wall pack types, understand key specs, and choose the right fixture for your site—then explore our Commercial Outdoor Lighting portfolio and nationwide coverage for fast support.

What Are Wall Pack Lights?

Wall pack lights are durable, building-mounted luminaires designed to illuminate perimeters, entrances, walkways, and loading zones. Modern LED wall packs deliver higher efficacy (lumens per watt), tighter optical control, and better cutoff options to reduce glare and light trespass compared with legacy HID fixtures.

Key Factors to Compare

1) Light Output (Lumens)

Size your lumen output to the task and mounting height. Higher mounting heights and wider areas typically require more lumens and a tighter optic. For security-critical zones, aim for consistent vertical and horizontal illuminance to improve facial recognition and camera performance.

2) Efficacy & Operating Cost

LED wall packs commonly exceed 120–150 lm/W. Power Select models help you right-size wattage on-site, trimming energy use without swapping fixtures.

3) Correlated Color Temperature (CCT)

Match CCT to environment: 3000K for hospitality and residential adjacencies, 4000K for balanced security + comfort, 5000K for maximum visibility in commercial/industrial settings. CCT Select models keep options open.

4) Optics & Cutoff

Choose full cutoff for the cleanest forward throw and minimal uplight (best for dark-sky and neighbor-friendly sites), semi-cutoff for a broader pool of light, and non-cutoff only for legacy look or special cases where maximum spill is acceptable.

5) Ratings, Build, and Reliability

Look for IP65 or higher for weather resistance, UL wet-location listing, and robust die-cast aluminum housings with powder coat finishes. A long warranty (typically 5 years) signals confidence.

6) Controls & Safety

0–10V dimming, photocells, motion sensors, and emergency battery backup stretch savings and coverage. Many sites blend dusk-to-dawn photocells with motion-activated boosts to full output after hours.

Types of Wall Pack Lights

Full Cutoff Wall Packs

Fully shielded optics direct light downward, reducing glare, uplight, and trespass—ideal for property lines, parking perimeters, and code-sensitive sites. See DarkShield Full Cutoff.

Semi-Cutoff Wall Packs

Balanced distribution with limited uplight to widen coverage while managing glare—good for broad walkways and building facades.

Non-Cutoff Wall Packs

Legacy-style wide distribution with higher spill. Use when appearance or special conditions warrant, and verify local ordinances first.

Infographic comparing full cutoff, semi-cutoff, and non-cutoff wall pack distributions, showing glare control and uplight differences.
Full cutoff minimizes glare and uplight for neighbor-friendly security lighting; semi-cutoff broadens the pool; non-cutoff maximizes spread.

Spec Comparisons: DarkShield & WallGuard

Both families feature rugged housings, selectable settings, and wet-location ratings. Use DarkShield when light control is the priority; choose WallGuard for traditional wall pack performance with strong output options.

DarkShield Technical Snapshot

DarkShield Series — Specifications
Model Wattage Range Lumen Output CCT Certifications
DarkShield Small 30–60W (Power Select) 5,350–9,641 lm 3000K / 4000K / 5000K (CCT Select) IP65, UL Wet Location
DarkShield Large 60–120W (Power Select) 5,190–19,320 lm 3000K / 4000K / 5000K (CCT Select) IP65, UL Wet Location
  • Optics: Full cutoff for controlled forward throw and reduced glare/trespass.
  • Controls: 0–10V dimming; field-installable photocell and motion sensor options.
  • Housing: Die-cast aluminum; outdoor powder coat; impact-resistant lens.
  • Warranty: 5-year limited warranty.
  • View DarkShield Series

WallGuard Technical Snapshot

WallGuard Series — Specifications
Model Wattage Range Lumen Output CCT Certifications
WallGuard Small (Full Cutoff) 30–60W (Power Select) 4,770–9,471 lm 3000K / 4000K / 5000K (CCT Select) IP65, UL Wet Location
WallGuard Large (Traditional) 60–120W (Power Select) 8,280–15,720 lm 3000K / 4000K / 5000K (CCT Select) IP65, UL Wet Location
  • Optics: Available in full cutoff and traditional distributions to match site goals.
  • Controls: 0–10V dimming; photocell and motion sensor compatibility.
  • Housing: Die-cast aluminum body; durable lens options; sealed against weather.
  • Warranty: 5-year limited warranty.
  • View WallGuard Series

Advanced Features & Controls

Photocell (Dusk-to-Dawn)

Automatically turns fixtures on at dusk and off at dawn to eliminate wasted runtime and manual scheduling.

Motion Sensing

Set baseline output to a low level, then boost to full when motion is detected—ideal for late-night security and energy savings.

0–10V Dimming

Integrate dimming with building controls to tailor light levels after hours or during low-traffic periods.

Emergency Backup

Battery packs keep egress paths lit during outages. Select capacity based on code and path-of-egress requirements.

Infographic explaining IP65 wet-location ratings for wall packs with icons for dust, water jets, and outdoor durability.
IP65 keeps dust out and resists water jets—exactly what perimeter fixtures face year-round.

Where Wall Packs Perform Best

  • Perimeter security on warehouses, distribution centers, and manufacturing facilities
  • Walkways, stair cores, and building entrances for safer navigation
  • Parking structures and receiving areas with camera coverage
  • Retail, education, and healthcare campuses seeking uniform, low-glare lighting

Explore application guidance and best practices: Commercial Lighting Applications.

Precision-Engineered Light for Demanding Environments

From warehouses and parking structures to educational campuses and medical facilities, every project deserves lighting engineered for lasting performance. The DarkShield Series and WallGuard Series by NCLTG combine selectable wattage, selectable color temperature, and rugged IP65-rated construction to deliver superior visibility and energy efficiency year-round.

Both families are backed by a 5-year warranty and supported through our nationwide network of lighting professionals. For project design, layout assistance, or specification guidance, explore our Commercial Outdoor Lighting collection or visit About NCLTG to learn how our team supports contractors, distributors, and facility managers with proven results.

Engineered for performance. Designed for reliability. Delivered nationwide.
