NCLTG
CanoLux Series LED Canopy Light – Power & CCT Select, 20W–40W, 3158–5835 Lumens, 3000K–5000K, 120–277V
CanoLux Series LED Canopy Light – Power & CCT Select, 20W–40W, 3158–5835 Lumens, 3000K–5000K, 120–277V
Specifications
Specifications
| Brand: | NCLTG |
| Manufacturer Part Number (MPN): | NC-CPS-40W-3CCT |
| Product Type: | Canopy Light |
| Light Source: | Integrated LED |
| Wattage/Lumen Options: | 20W - 3158 Lumens, 30W - 4561 Lumens, 40W - 5835 Lumens |
| Input Voltage: | 120-277V |
| Efficacy: | 138 to 161 lm/W |
| Current: | 0.37A |
| Dimming: | 0-10V |
| Color Temperature: | 3000K, 4000K, 5000K |
| CRI: | >80 |
| Light Distribution Pattern: | 145° |
| Power Factor: | >0.95 |
| THD: | <20% |
| Certifications: | UL Listed, DLC Premium Listed, IP65 Rated |
| Safety Rating: | Suitable for Wet Locations |
| Special Features: | Power Select Technology, CCT Select Technology, Built-In Photocell |
| Lens Material: | Polycarbonate |
| Housing Material: | Die-Cast Aluminum |
| Finish: | Bronze |
| Weight: | 4.63 Lbs. |
| Dimensions: | 10"L x 10"W x 2.75"H |
| Ambient Operating Temperature: | -30°C/-22°F to 50°C/122°F |
| Lifespan: | L70 @ >50,000 hrs @ 25°C/77°F fixture temperature |
| Warranty: | 5 Years |
About the CanoLux Series LED Canopy Lights
Why Choose CanoLux Series LED Canopy Lights?
CanoLux Series LED Canopy Lights from NCLTG are designed to meet the demanding requirements of outdoor and covered commercial spaces. With field-selectable wattages ranging from 20W to 40W and adjustable color temperatures from 3000K to 5000K, these fixtures provide customizable light output for a wide range of applications. Whether you need bright, high-output illumination for a parking garage or a warm, welcoming glow for a gas station, they deliver exceptional energy efficiency, enhanced safety, and long-lasting performance in any environment.
Durable, Weather-Resistant Construction
Built with a rugged die-cast aluminum housing and a weather-resistant polycarbonate lens, CanoLux Series LED Canopy Lights are ideal for demanding outdoor installations. They carry an IP65 rating and UL wet-location certification, ensuring they can withstand rain, snow, extreme temperatures, and other harsh environmental conditions. This durable construction provides reliable, low-maintenance performance and a long service life, even in the most challenging settings.
Maximized Customization for Every Need
Equipped with Power Select and CCT Select technologies, CanoLux Series LED Canopy Lights give you full control over both brightness and color temperature. This adaptability makes it easy to fine-tune lighting for any application—use a warm white tone to create a welcoming atmosphere or a cool white tone to boost visibility and security. With simple adjustability, these fixtures provide optimal lighting conditions across a wide range of environments.
Energy-Efficient and Cost-Effective
CanoLux Series LED Canopy Lights deliver high lumen output with minimal energy consumption, reaching efficacy ratings of up to 161 lm/W. This advanced efficiency allows businesses to reduce electricity costs without sacrificing bright, uniform illumination. Designed with an L70 rating of 50,000 hours, these fixtures offer exceptional durability and long-term savings, making them a cost-effective solution that minimizes maintenance and operational expenses.
Applications for CanoLux Series LED Canopy Lights
CanoLux Series LED Canopy Lights are versatile fixtures designed to deliver reliable illumination across a wide range of outdoor and covered spaces. Common applications include:
- Enhance visibility and improve safety throughout parking structures with bright, uniform lighting.
- Provide energy-efficient, high-output illumination for fueling areas and entrances.
- Increase pedestrian safety by lighting pathways and walkways with consistent, glare-free light.
- Create a welcoming, well-lit environment at building entrances for visitors and customers.
Why CanoLux Series LED Canopy Lights Stand Out
With advanced technology, flexible customization options, and rugged construction, CanoLux Series LED Canopy Lights deliver a superior lighting solution for outdoor and covered spaces. They are engineered to minimize energy use while producing bright, consistent illumination, making them ideal for a wide range of commercial applications. Offering long-lasting performance and significant energy savings, these fixtures stand out as a reliable choice for demanding environments.
